itel 5120Wh Lithium Battery Wall Mounted 48V 100Ah 5.12kWh IPW-51100

Product Description

itel 5120Wh Lithium Battery Wall Mounted 48V

iTel IPW-51100 LiFePO4 Battery – 48V 100Ah (5.12kWh)

Key Features:
✔ Ultra-Long Lifespan – 4,000+ cycles @80% DoD (10-year design life)
✔ Smart BMS Protection – 50+ safety algorithms for overcharge/over-discharge
✔ High Power Output – 100A continuous (150A pulse) discharge current
✔ Scalable Capacity – Parallel up to 15 units (76.8kWh total)
✔ All-Weather Ready – IP65 metal enclosure (-20°C to +60°C operation)
✔ Universal Compatibility – Auto-adaptive communication with hybrid inverters

Technical Specifications:

• Capacity: 100Ah (5.12kWh)

• Voltage: 48V nominal (40V–56.8V operating range)

• Charging: 55A standard (100A max) | 56.8V cut-off

• Dimensions: 450×600×150mm (wall-mount) | Weight: 52kg

• Communication: RS485/CAN/RS232 for monitoring

Certifications & Warranty:

• Safety: UL1973, CE, UN38.3

• Protection: Overcurrent/short-circuit/temperature

• Warranty: 5-year limited warranty

Ideal For:

• Whole-home solar storage

• Commercial energy backup

• Telecom base stations

• Off-grid microgrids
